Wire Cable Tray System

The wire cable tray system is the strongest system for guiding and protecting cables, pipes, flexible pipes and hoses. The ducts or cable trays are often used for cable management in data centers and server rooms.

Due to the large span capabilities of this DEFEM system, fewer brackets, rods and hanging elements are used. With the accessories and the options for easily creating connections, the installation of the cable ducts also takes little time. The savings on material and installation costs make it DEFEM wire cable tray system is therefore attractive from a cost perspective. Ideal for the laying and installation of electrical and telecommunications cables.

This cable support system from DEFEM is recommended for the organized and safe routing of cabling and pipework, for example under the ceiling or raised floors. The system meets the most important safety requirements and is DNV (Det Norske Veritas) certified.

The wire cable ducts / mesh trays are suitable for industries with specific requirements such as industrial automation (machine power cables and pipes) and the food industry (hygienic and easy to clean wire ducts). Due to the smooth surface, the cable trays can be easily cleaned and the stainless-steel material prevents corrosion on the steel. The open structure gives less chance of dust and the mesh cable trays are easy to clean. A wire duct offers a quick solution for concealing cables in small spaces. Attaching cables is easy, and inserting and removing them is also effortless.

Advantages of wire cable tray system:

• Excellent quality (very strong)
• Quick and easy to install, both vertically and horizontally, flexibly
• Cables, pipes, conduits and hoses are easy to attach with the cable loops/tyraps by Mulder-Hardenberg
• Cable entry and exit quickly and easily thanks to the wire pattern of the cable tray
• Optimal cooling due to open structure of the cable trays
• Cost effective on material and installation time
• Can be easily combined with the Warren and Brown fiber optic cable ducts / yellow ducts from Mulder-Hardenberg
• DNV – Det Norske Veritas certified
• Meets safety requirements

Characteristics:

• Cable tray C, G, Z & Mini Mesh width: 30, 46, 60, 75, 120, 220 mm;
• Cabletray C, G, Z & Mini Mesh height: 6, 15, 24, 75, 80, 95, 100, 130, 150 mm;
• Cable Tray C, G, Z & Mini Mesh length: 2.000 mm;
• Cable tray width: 53, 75, 120, 220, 320, 422, 522 en 622 mm;
• Cable tray height: 45, 55, 60 and 110 mm;
• Cable tray length: 2.500 mm;
• Available in gloss galvanized, galvanized and stainless steel 316 steel versions;
• Tested for function retention E30/E9.

Common areas of application:

Food and beverage industry Engels Machine construction and skid construction OEM – Original Electronic Manufacturer Datacenters – serverrooms Medical and pharmaceutical industry Offices and tertiary buildings Solar panels – PV Panels All kinds of technical rooms

Industry Infrastructure Shipping Off-shore Maritime sector Residential building Circularity Etc.

Mulder-Hardenberg will, if desired, carry out an inspection, provide tailor-made advice and come up with a free design. Mulder-Hardenberg also supplies high-quality ready-made products for simple and complex infrastructures in often demanding environments. The DEFEM wire cable tray system or cable car system is part of Mulder-Hardenberg’s cable management solutions.

Contact us and discover what else Mulder-Hardenberg can do for clients.
